Features

• Reflective technology

• Surface mount small outline leadless package

• Single channel incremental output

• Two channel quadrature outputs for direction sensing

• TTL compatible output

• Single 5V supply

• -20o

C to 85o

C absolute operating temperature

• Encoding resolution options:

36, 75, 150, 180 (lines/inch) or 1.42, 2.95, 5.91, 7.09

(lines/mm)
