Features and Benefits

⚫ DMOS Hall IC Technology.

⚫ Reverse bias protection on power supply pin.

⚫ Chopper stabilized amplifier stage.

⚫ Optimized for BLDC motor applications.

⚫ Reliable and low shifting on high Temp condition.

⚫ Switching offset compensation at typically 69 kHz.

⚫ Good ESD Protection.

⚫ 100% tested at 125 ℃ for K.

⚫ Custom sensitivity / Temperature selection are available.

⚫ RoHS compliant 2011/65/EU and Halogen Free

Applications

⚫ High temperature Fan motor

⚫ 3 phase BLDC motor application

⚫ Speed sensing

⚫ Position sensing

⚫ Current sensing

⚫ Revolution counting

⚫ Solid-State Switch

⚫ Linear Position Detection

⚫ Angular Position Detection

⚫ Proximity Detection

⚫ High ESD Capability
